Wifi Smart Camera -Outdoor Use :  ZDC-Q4IP
Multi-Angel View
Multi-Angel View
Multi-Angel View

Low power WiFI Smart Battery Camera

MODELZDC-Q4IP

Facebook Twitter InLink instagram Youtube Skype
  • Smart Life APP Control

  • Day/Night, IR distance: 20m

  • 2.0MP, 1080P HD images, resolution up to 1280x720P

  • Support external 64G Micro TF card

  •  Low consumption 4*18650 Lithium battery

  • IP65 waterproof level

  • WiFi 802.11b/g/n wireless network


Low power WiFI Smart Battery Camera: 1080P HD 2MP Waterproof Camera, 110°view angle, 20M IR Distance, IP65 Waterproof level, remote snapshot photos,Two way audio commnunication, Support 802.11b/g/n 2.4G Wifi,  Low consumption with 4*18650 Lithium battery.

- Low power smart WiFi Smart Camera

- IP65 Waterproof level.

- 2.0 Megapixel,110° wide viewing angle

- Support PIR motion detection,alarm push to mobile phone

- Support 2.4G Wi-Fi connection

- Support mobile phone & PIR detection wake up

- High Quality two-way intercom with noise cancellation

- Support Micro SD card up to 64GB
- Low consumption 4*18650 Lithium battery .
- Maintain 10-12months under 15s awoke everytime, 15 times every day



ModelZDC-Q4IP
Main ProcessorHi3518E
Sensor1/2.8 COMS
Video1920*1080@25fps
H.264 Bitrate self-adaptive
Suitable for changeable   network environments(3G,4G or WIFI)
AudioTwo-way voice & Support echo cancellation
Built-in speaker
Built-in Microphone
View Angle110 degree Horizontal
Day & NightIR-CUT double filter automatically switches
6pcs infrared LED 850mm
Min Illumination:1 Lux
ConnectionSupport WiFi 2.4 GHz, IEEE 802.11 b\g\n
AP Hot spot

Scan QR code
StorageSupport SD card 8G / 16G / 32G / 64G
RecordingSupport smart phone local record, records video playback
Optional   recording time setting between 15s-45s, once doorbell triggered
Screen ShotSupport Smart phone screen shots
Working ConditionPIR detection triggered
Mobile phone Control
Running upSystem running up in millisecond
InformPush message within 1s-2s
Motion DetectionPIR motion detection, sensitivity High(2s)/ Medium(within 5s)/ Low   (within 10 s)
Scene ModeBacklight compensation
Infrared night vision
Quick movement
HLC
D-WDR
ShareSupport QR code share(one-click generates QR-code, share to others
To add your doorbell devices,   join in remote control. Maximum supports 7 authenticated users, supports   users 3 view at the same time
Battery 3.7V, 4pcs 18650 battery, 4*2600mAH,
Power ConsumptionWorking 170mA, Standby 160μA


Package Contents:

  • Standard Exporting Packing Box
