Face Access Control: Multi-function standalone access controller and reader, WG26 output/Input Capacity: 1000 cards & pins /200 face, Face, card, pin 3 kinds of openning door method. The high security and more powerful feature make it an ideal choice for door access. By Master card for programming, it is so user friendly that anyone can use it.
With the flexible user capacity, it is suitable to be installed in office, shops,residential, villa, and banks etc.
- Support Facial Recognition, support RFID cards
- 100 Facial users,2000 RFID & pin users
- Wiegand output, wiegand input
- Besides standalone, it can connect to other controller as the salve reader
- Wiegand interface: wiegand 26
- Remote control / Master card for programming
- Metal shell, anti-vandal design.
- Anti-magnetic & lock output current short protect;
- Support connecting any card readers with wiegand interface, such as MF, EM
- Full of 2160 users, searching speed <0.1 S.
- DC input: 12DC,100mA
| Model | ZDAC-T5F |
| Face capacit | 100 |
| RFID card & Pin | 2000 |
| Supply Voltage | 12VDC±10% |
| Standby Current | <30mA |
| Operating Current | <300mA |
| Temperature | -15ºC-60ºC |
| Humidity | 20%RH-95%RH |
| Output protocol | WG26 |
| Access mode | Facial recognition, Card, Pin |
| Admin Card | admin card, admin fingerprint(add/delete) |
| Facial recognition distance | 50cm~1m |
