Waterproof Standalone Access Control: ZDAC-2200W
Multi-Angle View

Standalone Access Controller -Waterrpoof

MODELZDAC-2200W

Facebook Twitter InLink instagram Youtube Skype
  • IP68 Waterproof desgin

  • Plasticl case + backlit keypad

  • Identification way: Card, Pin, Card+Pin

  • Read Card type: 125Kz EM Card, or 13.56 MHzIC Mifare Card

  • 2000 users, with data backup function

  • WG26/WG34 input/ output,.

  • With Doorbell key, can connect with any external doorbell.


Waterproof Standalone Access Controller: The ZDAC-2200W uses the latest microprocessor technology to operate door strikes and security systems that require a momentary (timed) or latching dry contact closure. All programming is done through the keypad. Codes and operating parameters are stored within the microprocessor and can not be lost due to power failure.


The ZDAC-2200W can store 2000 prox cards and user 4~6 digit password codes; Three access way: Card, Pin, Card+Pin, Backligh keypad, WG26 input & output, with doorbell button to connect with wired doorbell, The unit has one relay output with 3 Amp changeover contact.


Standalone Access Controller -Waterrpoof(图1)

- IP68 Waterproof design
- Keystroke backlight

- with data backup function

- Card appliance: 125kHz EM ID cards, or 13.56 MHzIC Mifare Card
- Reading range: up to 5 cm
- Capacity:2000 users & prox cards
- Door open detection
Wiring Connections: Electric Lock, External Bell,  External Push Switch, Magnetic Contacts
- Alarm function
- Non volatile Eeprom memory
- Application: luxurious office building, bank, Prisons

Model

ZDAC-2200W

 Capacity 2000 cards
 Reading Distance 3~8CM
 Compatible Cards EM ID Card or 13.56 MHzIC Mifare Card
 Door Opening Time 0~99S (Adjustable)
 Voltage 12VDC+10%; Current 0.1A
 Temperature -45℃~60℃
 Humidity 20%~90%
 Dimension 145mm x 58mm x 22mm
 Weight 200g



Package Contents:

  • Standard Exporting Packing Box
